62 CCR TM8100/TM8200 Computer-Controlled Data Interface (CCDI) Protocol Manual
© Tait Electronics Limited April 2007
I03015BE Select toneset 0, ccir, 20ms tones and 5 tones notify
N04112387 Set ani to leading and tones 123
M01D0E Monitor “on”
M01E0D Monitor “off”
J03000C3 Volume level 0 (range is 0-255)
J03104BE Volume level 104 (range is 0-255)
2.8.2 Go to Receive Frequency
Description On receipt of this command, the radio checks the format and does a range
check on the frequency. If it is valid, the radio sends an ACK response and
then initialises the synthesizer with the new frequency. One should allow
20ms for the synthesizer to settle at the new frequency. If the command is
invalid, a NAK response will be sent and the receiver will remain at the last
selected frequency. If the radio is transmitting then a NAK response will also
be sent.
Command Rssxxxxxxxxxcc
Where:
Effect This command has immediate effect with the receiver retuning to this
channel. If the synthesizer is out of lock then a NAK response will be sent.
2.8.3 Load Transmit Frequency
Description On receipt of this command, the radio checks the format and does a range
check on the frequency. If it is valid, the radio sends an ACK response. If the
command is invalid, a NAK response will be sent and the transmit frequency
will not change. If the radio is transmitting then a NAK response will also
be sent.
Parameter Value
R ASCII letter R denotes the go to Receive frequency
ss ASCII hex number ss is the number of characters for parameters
(“08” or “09”)
xxxxxxxxx ASCII number xxxxxxxxx is the receive frequency, as follows:
■ Minimum is a number representing the bottom of the radio model
frequency band
■ Maximum is a number representing the top of the radio model
frequency band
cc ASCII hex number cc is the checksum
