12 Preparing the U-Bracket Installation TM8100/TM8200 Installation Guide
© Tait Limited November 2012
■ TMAC60 3-digit-display control head (TM8235 radio)
■ TMAC70 hand-held control head (TM8254 radio), with
TMAC34 remote control head, and TMAA10-06 remote speaker
(>25W radio) or TMAA10-03 remote speaker (25W radio)
The TMAC31, TMAC32 and TMAC34 remote interfaces are similar in
appearance to the TMAC30 RJ45 control head of the telemetry radio.
However, their electrical characteristics and signals are different. For
more information, refer to the installation instructions provided with the
remote kits.
3. TMAA02-01 microphone, TMAA02-08 keypad microphone
including microphone clip and screws (not required for the TM8105,
TM8252 or TM8254 radio)
4. A TMAA03-17 installation kit (>25W radio) or TMAA03-01
installation kit (25W radio), consisting of the following items:
■ U-bracket
■ thumbscrews
■ self-drilling screws and washers
■ power cable with DC connector
■ fuses
■ in-line fuse holders
■ receptacles for a remote speaker (remote speaker not included)
■ antenna connector
Refer to "Installation Kit Options" below.
Warning Danger of fire! The radio’s protection mechanisms
rely on the correct fuses on both the negative and positive power
supply leads being present. Failure to fit the correct fuses may
result in fire or damage to the radio.
The correct fuse types are:
■ >25W radios: 20A fuses (Tait IPN 265-00010-81)
■ 25W radios: 10A fuses (Tait IPN 265-00010-80)
Installation Kit
Options
Installation kits are also available without the U-bracket included and with
other antenna connector options. Consult your nearest Tait Dealer or
Customer Service Organization for more information.
