TM8100/TM8200 Installation Guide Preparing the U-Bracket Installation 11
© Tait Limited November 2012
2 Preparing the U-Bracket Installation
This section contains the following information:
■ installation tools
■ checking the equipment for completeness
■ choosing an installation configuration
2.1 Installation Tools
The following tools are required to install the radio:
■ drill and drill bits
■ Pozidriv screwdr iver
■ 5/16 inch (8mm) socket
■ RF connector crimp tool
■ fuse crimp tool
■ in-line RF power meter capable of measuring forward and reflected
power at the operating frequency of the radio
2.2 Checking the Equipment for Completeness
Unpack the radio and check that you have the following:
1. A radio body with one of the following product codes:
TM8100:
■ TMAB12 standard 25W radio
■ TMAB13 trigger-base 25W radio
■ TMAB14 standard >25W radio
TM8200:
■ TMAB22 standard 25W radio
■ TMAB23 trigger-base 25W radio
■ TMAB24 standard >25W radio
2. A control head with one of the following product codes:
TM8100:
■ TMAC10 blank control head (TM8105 radio)
■ TMAC20 2-digit display control head (TM8115 radio)
■ TMAC50 1-digit-display control head (TM8110 radio)
TM8200:
■ TMAC30 RJ45 control head (TM8252 radio)
■ TMAC40 or TMAC42 graphical-display control head
(TM8250 and TM8255 radios)
>25W 25W
