5.PipeCovers:TK‐PC01andTK‐PCJr2
The pipe cover protects the
plumbingpipestothewaterheater
from unexpected adjustments.
This pipe cover is fixed to the
bottom of the water heater, which
hides the plumbing and improves
the visual aspects of the whole
installationforthewater
heater.
6. Recessbox:TK‐RB02
TheRecessboxwillallowfor
“clean”installations.Thewater
heaterfitsinsidetherecessbox,
whichhidesandprotectsthe
wholewaterheaterandplumbing.
TheRecessboxwillfitin‐between
mostwallstuds.
7.T‐VentWallThimblewithTermination:TK‐KPWL4andTK‐KPWH4
Theseterminationsareusedwhenventingoutthroughthewall
andarecompatiblewiththeT‐Ventpipesystem.
Theseterminationsarespecialstainlessstee lventsforgas
appliancesandareULlistedasCategoryII,II IandIV.Thereare
twotypesofterminations:theLouverterminationandtheHood
termination.Fordifferentwallthicknesses,therearetworanges
oflength savailable(refertotheT‐Ventbrochurefordetails).
Installtheseventterminat ionsinaccordancewiththeir
installationinstructi on sandanyapplicable localcodes.
8.Direct‐VentConcentricTermination:TK‐KPCT43
Usedwhenterminatingdirect‐vent(sealed‐combustion)systems,
withdirect‐ventmodelsthatrequirea3”intakeand a4”exhaust.
Thisconcentricterminationprovidestheconvenienceofonly
havingtomakeonepenetrationthroughasidewallinsteadoftwo
separatepenetrationsfortheintakeandexhaustpiping.The
terminationincludes
abirdscreen,restrictingsmallanimals,
pests,andforeignobjectsfromenteringintotheventsystem.
Thissidewallterminationisavailableinthreedifferentsizes,to
coverallrangesofwallthicknesses.
Direct‐ventConcentricTermination
Part# Coveringwallthickness
TK‐KPCT43‐1 3.9”–7.1”
TK‐KPCT43‐2 6.9”–10.1”
TK‐KPCT43‐3 9.8”–13.0”
Louver
Termination
TK‐KPWL4
Hood
Termination
TK‐KPWH4
