Installation

23│Page



InanEasy‐Linksystem,thepumpmustbeconnectedtothe“Pump”connectorin

the“PARENT”unitonly.Ifthepumpisconnectedtoanyofthe“CHILD”units,the

pumpwillnotwork.

PUMPCONTROLMODE

(OnlyavailableontheT‐D2‐IN/OSmodels)

TheT‐D2‐IN/OSwaterheaterscanbeusedtocontrolarecirculationpump.Properpumpcontrolhelps

topreservethelifeofthesystemandsavesenergyaswell.



Thewa ter heaterpumpcontrolport isa“normally open dry contact”,andthereforeneedsadditional

componentstoproperly

controlarecirculationpump.

To control a recirculation pump, connect the pump to the “Pump” connector in the water heater as

showninthediagrambelow.(In anEasy‐Linksystem,connect thepumpONLY to the “PARENT” unit.)

Thepumpistobeconnectedusingsuitablerelaysshownin

thediagrambelow.

Pleasemakesuretherelaysareproperlyratedfortherecirculationpump.

Usingthewaterheater’sinternalthermistorsas atemperaturecontrol,therecirculationpumpwillonly

turnonwhenrecirculationisneeded.



CAUTION

ThesecomponentsareNOTincludedwiththewaterheaterandare

externaltotheunit.Theymustbeacquiredseparately.

Connectto this“Pump connector”.

Recirculation

pump

Thermal

relay

120VAC

220VACetc

forrelay

Powersupply

forpump

120VAC

220VACetc

Powersupply

forrelay
