Installation
8│Page


CLEARANCES













Model Top Bottom Front Back Sides
T‐KJr2‐IN* 12” 12” 24” 1” 2“
T‐KJr2‐OS 36” 12” 24” 1” 2“

Model Top Bottom Front Back Sides
T‐K4‐IN* 12” 12” 24” 1” 2“
T‐K4‐OS 36” 12” 24” 1” 2“

Model Top Bottom Front Back Sides
T‐D2‐IN* 12” 12” 24” 1” 2“
T‐D2‐OS 36”  12” 24” 1” 2“
*Standardindoorinstallations&direct‐ventindoorinstallationshavethesameclearances.





INCLUDEDACCESSORIES

Checkthattheseitemsbelowareincludedwiththewaterheater.

1. Installation Manual &
Owner’sGuide

2. ProductRegistrationCard  3.CommunicationCable
(OnlyT‐D2‐IN&T‐D2‐OSmodels)










Qty:1
Qty:1
Qty:1
Bottom
Side
Top
Side
Front
Back
Maintain all clearances around
thewaterheater.
