NormalOperation
33│Page
• Flowratetoactivatethewaterheater:0.75gallonperminute
• Flowratetokeepthewaterheaterrunning:0.4gallonperminute
• HotWatertemperaturesover125°F(52°C)cancausesevereburnsinstantlyor
deathfromscalding.
• Theoutlethotwatertemperatureofthewaterheaterisfactory
setat122°F(50°C).
• Feelthewatertemperaturebeforebathingorshowering.
NORMALOPERATION
GENERAL








1. Openahotwatertap.*


2. Mixcoldwaterwiththehottoget
thecorrecttemperaturewater.




3. Closethehotwatertap.






*Ifaremotecontrollerinstalled,turntheremotecontrollerONbypressingthepowerON/OFFbutton
ontheremotecontrollerandthensetthetemperaturebypressingtheHOT/COLDbuttons before
openingahotwatertap.Thetemperatureisdisplayedwhentheremotecontro lleristurnedON.

TEMPERATURESETTINGS
‐Withoutremotecontroller‐
Depending on the model, there are 4 or 8 temperatures that you can select from by changing the
dipswitchsettingsonthecomputerboardwithouttheremotecontroller.Seethetablebelow.
Model Temperaturesavailable
T‐KJr2‐IN/T‐KJr2‐OS,
T‐K4‐IN/T‐K4‐OS
113°F 122°F 131°F 140°F
T‐D2‐IN
T‐D2‐OS
104°F 113°F 122°F 131°F 140°F 158°F 176°F 185°F
Fordetaileddipswitchsettingsforeachtemperature,refertothenextpage.
• Thetemperaturehasbeenpresetatthefactoryto122°F(50°C).
• If temperatures other th an the ones listed above are require d, the remote controller can
provideseveralmoretemperatureoptions.Refertop.9foralist
ofavailabletemperatureson
theremotecontroller.
• This water heater is an on‐demand, tankless water heater designed to efficiently supply
endlesshotwaterwithoutreferencetotemperaturesettings.
NOTICE
WARNING
