Takagi T?K4?IN User Manual

Installation
21│Page
Followtheelectricalcoderequirementsofthelocalauthorityhaving
jurisdiction.Intheabsenceofsuchrequirements,followthelatesteditionof
theNationalElectricalCodeANSI/NFPA70intheU.S.orthelatestedition of
CSAC22.1CanadianElectricalCode,Part1,inCanada.
Whenservicingorreplacingpartswithinthewaterheater,labelallwires
priortodisconnectiontofacilitateaneasyanderror‐freereconnection.
Wiringerrorscancauseimproperanddangerousoperation.Verifyproper
operationafterservicing.

ELECTRICALCONNECTIONS
1. Thewaterheatermustbeelectricallygrounded.Donotattachthegroundwiretoeitherthegasor
thewaterpiping.

2. Thewaterheaterrequires120VAC/60Hzelectricalpowersupplythatisproperlygrounded.
• A proper disconnect (i.e. on/off switch, power plug, etc.) controlling the main power to the
waterheatermustbeprovidedforservicereasons.(Mustcomplywithlocalcodes).
• Connect thepowersupply
tothewaterheaterexactlyasshowninthewiringdiagram;

3. Agreenscrewisprovidedinthejunctionboxtogroundtheconnection.
4. Canbehardwiredorwiredtoaplug‐in.
5. Theuseofasurgeprotectorisrecommendedinordertoprotecttheunit
frompowersurges.





















CAUTION
WARNING
ConnectPowersupply
120 VAC
/
60Hz
Ground
Bottomviewofwaterheater
Viewofelectrical connectionsofwaterheater
Greenscrew
