2-51
CONTROLS
c. Stop the engine and wait for at least 5
minutes until bubbles escape from the
hydraulic oil in the tank.
IMPORTANT: Follow the procedures for
purging air as instructed by the
attachment manufacturer, if applicable.
6. Check for oil leaks.
ACCESSORIES
Operating the auxiliary hydraulic circuits
1. Operate the auxiliary hydraulic buttons as
follows.
Auxiliary hydraulic buttons
To discharge from the hydraulic oil port (e)
.................................................... Press (E)
To discharge from the hydraulic oil port (f)
....................................................Press (F)

Takeuchi TL10 Specifications

General

Engine Make	Kubota
Engine Power	74.3 hp
Tipping Load	7, 205 lb
Rated Operating Capacity	2, 522 lbs
Engine Model	V3307-CR-TE4
Max Dump Height	2, 540 mm
Overall Width	1, 800 mm
Overall Height	2, 540 mm
Travel Speed	11.5 km/h
