Takeuchi TL10 User Manual

5-23
MAINTENANCE
DAILY INSPECTION (EVERY 10 HOURS)
INSPECTING AND REMOVING
COMBUSTIBLE MATERIALS FROM THE
REAR AND BELLY OF MACHINE
Do not operate the machine without
properly inspecting for vegetation, wood
chips, dust, fuel, oil, and other
combustible material. Remove any
combustible material prior to machine
operation to reduce the risk of fire.
1. Open the engine hood (1) and the rear
door (2).
2. Remove materials such as vegetation,
wood chips, dust, fuel, and oil around
engine compartment (3), battery (4),
radiator (5).
3. Inspect the machine thoroughly for any
combustible materials within the towers
(6), around and under the cabin.

Takeuchi TL10 Specifications

General

Engine Make	Kubota
Engine Power	74.3 hp
Tipping Load	7, 205 lb
Rated Operating Capacity	2, 522 lbs
Engine Model	V3307-CR-TE4
Max Dump Height	2, 540 mm
Overall Width	1, 800 mm
Overall Height	2, 540 mm
Travel Speed	11.5 km/h
