2-16
CONTROLS
MULTI-DATA DISPLAY
17. LCD (Liquid Crystal Display)
IMPORTANT: If the vehicle and engine
emergency lamp flashes and a number
appears on the vehicle or engine error
code screen, refer to the “Vehicle error
code list” or “Engine error code list” and
contact your sales or service dealer for
help
INSTRUMENT CLUSTER
When the ignition switch is turned to ON, the
display of hour meter, trip meter or the
various data items on the machine appears.
The initial screen displays the hour meter, the
trip meter or the PM accumulation amount.
PM: Particulate matter
Press either the TRIP (1) side or the DATA (2)
side to select a display mode.
• Press the TRIP (1) side to display the hour
meter, trip meter or the amount of PM
deposition.
• Press the DATA (2) side to display the
various data.
Trip/Data switch
