3-3
OPERATION
STARTING AND STOPPING
THE ENGINE
BEFORE STARTING THE ENGINE
1. Adjust the seat for a comfortable operating
position.
2. Fasten the seat belt.
STARTING AND STOPPING THE ENGINE
3. Check that the safety bar is in the lock
position.
4. Check that all levers and the pedal are in
the neutral position.
5. Insert the key into the ignition switch, turn
it to the ON position, and then perform the
following inspections:
· All warning lamps flash and an alarm is
sounded for two seconds. The meters
also start functioning. After two seconds,
only the battery charge warning lamp (1)
and engine oil pressure warning lamp (2)
remain flashing, and the other lamps go
out. The Aux. 1st flow rate indicator
lamp is lit all the time.
· Turn the light switch to check that the
front lights, tail lights and meter light turn
on.
· Check the fuel level.
If a lamp does not light or the alarm is not
sounded, the bulb may be burnt out or a
wire may be damaged. Ask a Takeuchi
service agent for repair.
