Takeuchi TL10 User Manual

5-10
MAINTENANCE
LIST OF TOOLS (IF EQUIPPED)
SERVICE DATA
Code Part name Part No. Remarks
1 Spanner 16900-01012 10-12
2 Spanner 16900-01113 11-13
3 Spanner 16900-01417 14-17
4 Spanner 16900-01922 19-22
5 Spanner 16900-02427 24-27
6 Spanner 16901-00030 30
7 Spanner 16901-00041 41
8 Screwdriver 16902-20205 (+) (–) replaceable shank
9 L-type wrench 16908-30019 19
10 Hammer 16903-00330 3/4
11 Monkey wrench 16904-00250 250 mm
12 Pliers 16905-00200 200 mm
13 Hex.wrench 16906-00500 5 mm
14 Hex.wrench 16906-00600 6 mm
15 Hex.wrench 16906-00800 8 mm
16 Hex.wrench 16906-01000 10 mm
17 Hex.wrench 16906-01400 14 mm
18 Tool case 16914-00005
19 Case 16919-00001
20 Grease gun 16910-60600 600 cc
21 Drain connector 15545-12601

Takeuchi TL10 Specifications

General

Engine Make	Kubota
Engine Power	74.3 hp
Tipping Load	7, 205 lb
Rated Operating Capacity	2, 522 lbs
Engine Model	V3307-CR-TE4
Max Dump Height	2, 540 mm
Overall Width	1, 800 mm
Overall Height	2, 540 mm
Travel Speed	11.5 km/h
