3-13
OPERATION
3. Roll back the bucket all the way, and then
lift it to 30 cm (12 in.) above the ground.
Moving the machine forward and
backward
1. Operate the left control lever as below.
OPERATING THE MACHINE
To move forward:
Push the left control lever forward.
To move backward:
Pull the left control lever backward.
Traveling in 2nd (High) speed
Press the travel speed button on the left
control lever to switch to 2nd (high) speed,
and press it again to return to 1st (low) speed.
Pivot turn
Turning to the left:
To turn forward to the left:
Tilt the left control lever forward to the
left.
To turn backward to the left:
Tilt the left control lever backward to the
right.
To turn to the right, operate the left control
lever in the opposite way.
Spin turn
To spin left:
Tilt the left control lever to the left.
To spin right:
Tilt the left control lever to the right.
