Takeuchi TL10 User Manual

6-15
TROUBLESHOOTING
ENGINE ERROR CODE LIST
Error code
Error details
SPN FMI
523538
2 QR data error
7 QR data writing error
523539 2 Pump seizure 1
523540 2 Pump seizure 2
523543 2 Main unit side accelerator sensor error
523544
3 Air heater relay drive circuit, battery short-circuit
4 Air heater relay drive circuit, GND short-circuit
523547 2 CAN 2 BusOff error
523548 2 CAN_KBT original frame cable break error
523572 4 EGR position sensor error
523574
3 EGR motor cable break error
4 EGR motor short-circuit error
523575 7 EGR valve sticking error (FB error)
523576 2 EGR motor environment temp. error
523577 2 EGR valve’s integrated thermistor sensor error
523578 2 EGR control line communication breakdown (cable break)
523580 2 Air-intake throttle feedback (FB) error
523582
3 Air-intake throttle lift sensor error, High
4 Air-intake throttle lift sensor error, Low
523589 17 Water temp. rise insufficient at manual regeneration
523590 16 Time-up error at manual regeneration
523591 2 CAN_CCVS communication breakdown error
523592 2 CAN_ CM1 communication breakdown error
523595 2 CAN_ETC5 communication breakdown error
523596 2 CAN_TSC1 communication breakdown error
523598 2 CAN_EBC1 communication breakdown error
523599 0 All exhaust temp. sensors’ cables break simultaneously error
523600 0 Warning about incomplete learning of differences between pumps
523601 0 Continued abnormal exhaust temp. error (starter relay drive inhibit warning)
523602 0 Regeneration frequency too high error
523603 15 High. Temp_AECD actuation warning
523604 2 CAN 1 BusOff error
523700 13 KBT area EEPROM checksum mismatch

Takeuchi TL10 Specifications

General

Engine Make	Kubota
Engine Power	74.3 hp
Tipping Load	7, 205 lb
Rated Operating Capacity	2, 522 lbs
Engine Model	V3307-CR-TE4
Max Dump Height	2, 540 mm
Overall Width	1, 800 mm
Overall Height	2, 540 mm
Travel Speed	11.5 km/h
