7-8
SPECIFICATIONS
MACHINE DIMENSIONS
Item
Standard bucket
Rubber tracks
A Overall length 3985 (156.9)
B Overall length (without bucket) 3135 (123.4)
C Track base 1595 (62.8)
D Overall height 2320 (91.3)
E Ground clearance of undercarriage 345 (13.5)
F Overall width (without bucket) 1860 (73.2)
G Track shoe width 450 (17.7)
H Body width 1570 (61.8)
J Canopy/Cab width 985 (38.8)
K Bucket width 1960 (77.2)
L Bucket height 580 (22.8)
M Departure angle 30°
<TL12>
Unit: mm (inch)
