Tally Dascom 1125
19
Power-On State
Function
Name
Switch
Operation
LED Function Description
Status Page /
Self Test
[S4] -
Prints the printer settings and self-test pattern.
Pressing S1 can change the font.
Hex Dump [S3] L4
Beeps once to indicate going into hex dump mode:
· Prints data from host in hexadecimal representation.
· Lights up L4.
· Pressing S4 suspends the printing.
· When the hex dump has finished, pressing S4 forces the
printing of the last line of data, as any line termination
control code from host has no function.
· Pressing S1 can change the font.
· Switch off the power to terminate the hex dump.
Firmware
Update
[S1]+[S2]+
[S3]+[S4]
L1, L2,
L3, L4
· Alternate flashing of L3 and L4 indicates printer is ready
for firmware update. L1 and L2 are ON and OFF
respectively.
· When new firmware is being received, L3 and L4 are set
to ON. L1 flashes a few times and then sets to ON. L2
flashing indicates downloading in progress.
· When downloading is completed, the carriage returns to
home position. Printer initializes normally.
