35 TASCAM CD-BT2
Other functions
Using the tuner
This device has a built-in tuner that can be used not only for
tuning a bass, but also for outputting a tuning pitch that you
select.
First, select the tuner mode.
1 Press the TUNER key to open the TUNER screen.
2 With the MODE value selected, use the VALUE (+, –)
keys to select one of the following tuner modes.
AUTO chromatic tuner
BASS bass tuner
OSC. oscillator mode
These modes are explained separately in the following
sections.
AUTO (chromatic tuner)
In this ordinary mode, you do not need to change settings for
each of the strings being tuned. The tuning meter and input
signal pitch appear on the screen (see the preceding gure).
(“---” appears when there is no input).
1 Connect a bass to the BASS IN jack and play the string
that you want to tune. The pitch closest to the string’s
frequency appears at the top of the meter.
2 Tune the bass roughly until the desired pitch name is
shown. Fine tune the bass until the center of the meter
is highlighted. A bar appears to the left if the tuning is
too low and a bar appears to the right if it is too high.
The longer the bar is the more out of tune the string is.
Use the CURSOR ¶ key to select CALIB, and the VALUE
(+, –) keys to set the standard frequency of middle A
between 435 Hz and 445 Hz.
This setting affects all tuner modes.
