Taski swingo 1255B

GTS Technical Manual
19. April 2010 Edition: V1.00/2010 4-7
Copyright © 2010, Diversey Inc.
04.0 swingo 1255 B Power - technical data.fm
4.2.6 Charger
4.2.7 Brush system
Supplier Type
Voltage Ah Length [mm] Width [mm] Height [mm] Weight [kg]
Excide Sonnenschein GF12050 12 50 278 175 190 20
Excide Sonnenschein GF12070 12 70 330 171 236 28
Table 7: Dry (gel) batteries
Pos. Value
Primary V 100 - 240
Primary Hz 50 - 60
Secondary V 24
Secondary A 20
Secondary (DK model) A 25
Protection class charger (BMS model) I
Protection class charger (BMS model DK) II
Approval CE
Cable length / BMS cable (m) 3
Table 8: Charger
Pos. Value
Brush system (mm) 2 x 280
Brush motor (W) 750
Brush speed (rpm) 195
Brush pressure max. (kg) 48
Table 9: Brush system
