GTS Technical Manual
19. April 2010 Edition: V1.00/2010 5-7
Copyright © 2010, Diversey Inc.
05.0 swingo 1255 B Power - mechanics.fm
Remarks
Ensure that the vacuum motor sealings are properly positioned
before assembling the protection plate.
• Position and tighten the vacuum motor protection plate
fixation.
Remarks
Ensure that the turn protection is placed (spin protection).
• Mount capacitor to the vacuum motor and connect wires.
• Position top sealing of vacuum motor.
• Connect vacuum motor wires to connection block.
• Close tank cover and position it on the base plate.
• Open tank cover together with base plate.
• Use the tank cover support.
• Tighten base plate fixation on the LH side.
• Tighten base plate fixation on the tank support side (RH).
Tighten the fixation rubbers smoothly.
Remarks
Check at the end if the vacuum motor top sealing is positioned
properly. If necessary, unscrew and remove the dashboard and
check.
