GTS Technical Manual
19. April 2010 Edition: V1.00/2010 5-10
Copyright © 2010, Diversey Inc.
05.0 swingo 1255 B Power - mechanics.fm
Remarks
Check at the end if the vacuum motor top sealing is positioned
properly. If necessary, unscrew and remove the dashboard and
check.
• Open tank cover.
• Assemble tank cover lock.
Adjustment
Adjust the tank cover lock and ensure a proper opening and closing
of the tank cover.
• Mount the rear panel.
• Assemble handle on the tank cover with the 7 screws.
• Position the complete throttle lever system.
• Thread in the hall sensor cable to the dashboard.
• Fix the throttle lever bracket with the screws.
• Position wires on the external hour counter or on the handle
cover, depending on the setup.
• Mount the handle cover.
• Connect wires to dashboard.
• Assemble dashboard on the tank cover.
