3.5.3 List of parts
The remote control consists of two parts.
1. INFRARED TRANSMITTER (the source)
2. INFRARED RECEIVER
The infrared transmitter is mounted on the handle. The infrared receiver is installed in the computer.
3.5.4 Main functions of the infrared transmitter
The infrared transmitter has four buttons = MENU button - ENTER button - SELECT button (DOWN -
UP). These four buttons are exactly the same buttons as those on the COMPUTER.
See COMPUTER MANUAL for detailed information about the button functions.
Infrared LED Transmitter
Infrared Receiver
Handlebar
MENU button
ENTER - Display button
SELECT buttons
- +
UP & DOWN
