001 1 Aluminum Beam 115 4 Standard Cap
002 1 Main Frame 116 1 Aluminum Beam End Cap
003 1 Pivot Bracket 117 2 Carriage Cover
005 1 Stabilizer - Front 118 4 Seat Carriage Roller
006 1 Stabilizer - Rear 119 1 Seat
007 1 Rear Bracket 122 2 Plug
008 1 Ali Handle Bar 123 1 Foam Grip
009 2 Seat Carriage 124 4 Carriage Stopper
010 2 Seat Carriage Shaft 129 1 Cover Vent
011 4 Roller Adjustment Bolt 132 1 Strap Slot Trim
012 4 Roller Adjustment Plate 134 1 Poly “V” Drive Belt
013 1 Foot Pedal 135 1 Drive Pulley
015 1 Computer Arm 136 1 Strap Drum
017 1 Clutch Shaft 137 1 Return Spring - Drum
018 1 Return Spring 138 1 Return Spring -Cover
019 2 Roller Spacer 139 1 Return Spring - Holder
026 1 Stopper Bracket 140 1 Flywheel Fan
027 2 Strap Holder 142 2 Special Seat Roller
028 1 Knob Stud 143 2 Heel Rest
029 2 Spring 144 2 Plug
030 1 Handle 146 1 Plug
103 2 Computer Arm Plug 147 2 Heel Rest Holder
104 2 Computer Arm Pivot 149 2 Bushing
105 2 Computer Arm Plug Cover 150 2 Ball Knob
106 2 Computer Case Nut Cover 151 1 Sensor Holder
107 2 Computer Arm Spacer 153 1 Receiver Cover
110 1 “V”Cover 154 4 Strap Trim
111A 1 Cover Main - Right 161 1 Infrared Transmitter-Top
111B 1 Cover Main - Left 162 1 Infrared Transmitter-Battery
Holder
113 4 Wheel 163 1 Infrared Transmitter-Bottom
59
8.2 Parts List
No. Qty. Description No. Qty. Description
