3.5.6 Infrared range and direction
The remote control should be directly aligned with the training computer.
Wrong
Right
ANGLE OF THE INFRARED RECEIVER OF THE COMPUTER VS. HANDLE POSITION
In the picture the angle of the infrared receiver of the computer is wrong and the
infrared transmitter of the handle is too far away from an angle of the infrared
receiver of the computer
In the gure the angle of
the infrared receiver of the
computer is correct and
the infrared transmitter of
the handle is in the correct
position to the angle of
the infrared receiver of the
computer.
