6-4
OPERATING PROCEDURES
Model 8756
Operating Procedures
6
5. Insert the prime plugs into the holes at the top of the
freezer door and push down.
Figure 6-11
6. Insert the baffle rods through the beaters in the
freezing cylinders.
Figure 6-12
7. With the door seated on the freezer studs, install the
short handscrews on the bottom and the long
handscrews on the top. Tighten the handscrews
equally in a crisscross pattern until the door is
secured.
Figure 6-13
Draw Valve
1. Slide the two O-rings into the grooves on the draw
valves and lubricate each O-ring.
Figure 6-14
11428
Apply the appropriate
Taylor approved food safe lubricant.
