40
Models C708 & C716Operating Procedures
Step 4
Insert the piston into the retaining pin hole end of the
pump cylinder. (See Figure 38.)
Figure 38
Step 5
Assemble the valve cap. Slide the o-ring into the
groove of the valve cap. DO NOT lubricate the
o-ring. (See Figure 39.)
Figure 39
Step 6
Slide the pump valve gasket into the holes on the
cap. DO NOT lubricate the gasket. (See Figure 40.)
Figure 40
Step 7
Insert the valve body cap into the hole in the mix
inlet adapter. (See Figure 41.)
Figure 41
Step 8
Insert the mix inlet assembly into the pump cylinder.
(See Figure 42.)
Figure 42
The adapter must be positioned into the notch
located at the end of the pump cylinder.

Other manuals for Taylor C716

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Taylor C716 and is the answer not in the manual?

Taylor C716 Specifications

General IconGeneral
Hopper Capacity20 quarts (18.9 liters)
Separate Hopper Refrigeration (SHR)Yes
Air CooledYes
Freezing CylinderOne
Mix HopperOne
Electrical208-230/60/1
Motor1.5 HP
Indicator LightsMix Low
Refrigeration SystemAir Cooled
