Model 390 Tim Hortons Important: To the Operator
100927
Section 5 Important: To the Operator
Figure 4
ITEM DESCRIPTION
1 POWER SWITCH
2 RESET BUTTON
3 LIGHT-MIX OUT
4 LIGHT-ADD MIX
5 LIGHT-SPINNER
The following chart identifies the symbol definitions
used on the unit label.
= “WASH” key
= “OFF”
= “ON/AUTO” key
