Model 390 Tim HortonsImportant: To the Operator
Power Switch
The center position is “OFF”. The “AUTO” position
activates the beater motor and the refrigeration
system. The “WASH” position activates the beater
motor only.
Reset Button
The reset button is located in the left side panel. The
reset protects the beater motor from an overload
condition. If an overload occurs, the reset
mechanism will trip. To properly reset the freezer,
place the power switch in the “OFF” position. Press
the reset button firmly. Place the power switch in the
“WASH” position and observe the freezer's
performance. Once satisfied, place the control
switch back in the “AUTO” position.
IMPORTANT: Do not use metal objects to
press the reset button.
“ADD MIX” Indicator Light and
Alarm
The “ADD MIX” indicating light is located on the front
of the machine. The indicator light will flash and an
audible tone will sound when the mix hopper has a
low supply of product. Refill the hopper as soon as
possible.
“MIX OUT” Indicator Light
The “MIX OUT” indicating light is located on the front
of the machine. The indicator light will flash to
indicate that the mix hopper is empty and the mix
supply needs to be replenished. To prevent damage
to the unit, refrigeration discontinues automatically.
Spinner Indicator Lights
The spinner indicator lights are located on the front
of the machine, one above each spinner assembly.
The spinner indicator lights are activated by pressing
the respective spinner motor switches. The lights
illuminate for 15 seconds, indicating the proper blend
time.
IMPORTANT: Taylor recommends daily
cleaning and sanitizing.
FOLLOW YOUR LOCAL HEALTH CODES.

Taylor Tim Hortons 390 Specifications

General

Brand	Taylor
Model	Tim Hortons 390
Category	Freezer
Language	English
