TDK-Lambda GH10-150 - Output Connector for Models above 100 VDC Output; Serial Link Cable; Misc. Hardware; Optional Accessories

25
• SEMS screw M3X40, Type DIN 7985A, Inox A2, 1 Pc.
• Flat Washer M3, Type DIN433, Inox A2, 1 Pc.
1.3.1.4 Output connector for models above 100VDC output
• P/N: GIC 2.5/4-ST-7,62 by Phoenix Contact.
• Output terminal plugs P/N: MB-01F, 2 Pcs.
1.3.1.5 Serial link cable
Serial link cable for linking power supplies by RS485 communication.
Cable description: 0.5m length, shielded, RJ-45 type plugs, 8 contacts (P/N: GEN/RJ45).
1.3.1.6 Misc. hardware
• DB-26 Connector P/N: 10090769-P264ALF (FCI).
• DB-15 Backshell (used for DB-26 Connector) P/N: 86303638BLF (FCI).
• SEMS Screw M3X6 Fe Ni, 2 Pcs.
• Foot snaps and matching push rivets, 4Pcs.
• CD-ROM.
• Safety & Installation Manual.
1.3.1.7 Bus bars screws kit
• Hex. Screw M6X16 St. St., Type DIN933, 2 Pcs.
• Hex. Nut M6 St. St., Type DIN439B, 2 Pcs.
• Flat washer M10 St. St., Type DIN125A, 4 Pcs.
• Spring washer M10 St. St., Type DIN127B, 4 Pcs.
1.3.2 Optional Accessories
1.3.2.1 Printed user manual
• For ordering printed User Manual, the P/N is: G/M
1.3.2.2 Serial port cables
• For ordering serial port cables, refer to the User Manual (printed or in the CD-ROM).
• USB/LAN cables are not provided with the power supply.
1.3.2.3 Paralleling cable
• For ordering paralleling cables, the P/N is: G/P.
1.3.2.4 Rack mount kit
Refer to section 4.4
NOTE
Optional accessories will be sent separately from the power supply packing according to order.
