29
No.
Control/Indicator
Description
16 PREV Button / Indicator
Press the PREV button to display the Output Voltage and Current Limit
settings.
The display shows the settings for 5 seconds.
If buttons are not pressed for 5 seconds, the display returns back to show
actual output voltage and current.
If Voltage or Current values are changed, and there is no keypress for 15
seconds, the display returns back to show actual output Voltage and
Current.
Green LED lights when PREV mode is active.
17 OUT Button / Indicator
Output ON/OFF control. Press OUTPUT to set the output ON or OFF.
Green LED lights when DC Output is enabled.
Red LED blinks in case of an alarm. Refer to User Manual, Alarms and
Protective Functions section.
Table 2-1: Front Panel Controls and Indicators
NOTE
* If a menu is active, and there is no key press within 15 seconds, power supply returns to the main
display (OFF or actual Voltage and Current display).
