63
SAFETY/EMC
1.Safety standards
---
UL60950-1, CSA22.2 No.60950-1, IEC60950-1, EN60950-1.
1.1.Interface classification
---
Vout≤40V Models: Output, J1, J2, J3, J4, J5, J6, J7, J8 (sense) and J9 (communication options) are
SELV.
60≤Vout≤600V Models: Output and J8 (sense) are hazardous, J1, J2, J3, J4, J5, J6, J7 and J9
(communication options) are SELV.
1.2.Withstand voltage
---
Vout≤40V Models: Input - Output (SELV): 4242VDC 1min, Input - Ground: 2835VDC 1min.
60V≤Vout≤100V Models: Input - Output: 4242VDC 1min, Input - SELV: 4242VDC 1min.
Output - SELV: 850VDC 1min, Output - Ground: 1500VDC 1min, Input - Ground: 2835VDC 1min.
100V<Vout≤600V Models: Input - Output: 4242VDC 1min, Input - SELV: 4242VDC 1min
Output - SELV: 1500VDC 1min, Output - Ground: 2500VDC 1min.
Input - Ground: 2835VDC 1min.
1.3.Insulation resistance
---
More than 100Mohm at 25
O
C, 70%RH.
2.EMC standards (*4)
---
IEC/EN61204-3 Industrial environment.
2.1.Conducted emission
---
IEC/EN61204-3 Industrial environment, Annex H table H.1, FCC Part 15-A, VCCI-A.
2.2.Radiated emission
---
IEC/EN61204-3 Industrial environment, Annex H table H.3 and H.4, FCC Part 15-A, VCCI-A.
NOTES:
*1: Minimum voltage is guaranteed to maximum 0.1% of rated output voltage.
*2: Minimum current is guaranteed to maximum 0.2% of rated output current.
*3: For cases where conformance to various safety standards (UL, IEC, etc…) is required, to be described as 100-240Vac (50/60Hz).
*4: Signal and control ports interface cables length: Less than 3m, DC output power port cables length: Less than 30m.
*5: Not including EMI filter inrush current, less than 0.2mS.
*6: 85~132Vac or 170~265Vac. Constant load.
*7: From No-Load to Full-Load, constant input voltage. Measured at the sensing point in Remote Sense.
*8: For 10V~150V models: Measured with JEITA RC-9131C (1:1) probe. For 300~600V models: Measured with 100:1 probe.
*9: For load voltage change, equal to the unit voltage rating, constant input voltage.
*10: The maximum voltage on the power supply terminals must not exceed the rated voltage.
*11: From 10% to 90% or 90% to 10% of Rated Output Voltage, with rated, resistive load.
*12: From 90% to 10% of Rated Output Voltage.
*13: For 10V model, the ripple is measured at 20~100% of rated output voltage and rated output current. For other models, the ripple is measured at 10~100% of rated output
voltage and rated output current. B.W 5Hz~1MHz.
*14: The Constant Current programming, readback and monitoring accuracy do not include the warm-up and Load regulation thermal drift.
*15: Measured at the sensing point.
*16: Maximum ambient temperature for IEEE option is 40°C.
*17: Ta=25°C, rated output power.
