3-2-3. Output voltage external control function (Apply external power to CV terminal)
Connect the external power supply between the CV terminal (pin No. 16 of CN41 or CN42) and the AG terminal
(pin No. 11 or pin No. 12 of CN41 or CN42).
Use twisted or shielded signal wires.
3-2-4. Output current external control function (Apply external power to CC terminal)
Connect the external power supply between the CC terminal (pin No. 15 of CN41 or CN42) and the AG terminal
(pin No. 11 or pin No. 12 of CN41 or CN42).
Use twisted or shielded signal wires.
