Teac HDB843 - Connections and preparation; Connecting to TV

9
Connections and preparation
Connecting to TV
Connect the three AV cable between the 'CVBS R L' or 'YPbPr' sockets on the STB
and the same sockets on your TV.You can do it follow the figure below.
s
ANTENNA
S VIDEO-
VIDEO R AUDIO L--
Turn on the power switch in the back of the set-top box
8
TO AERIAL INPUT
SOCKET ON TV SET
ANT IN
ANT OUT
OFF
ON
YPbPr
R
L
CVBS
AC90 240V
50Hz 60Hz
10W max
-
/
SVIDEO -
OPTICAL
USB
()For upgrade only
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
SHOCK HAZARD DO NOT OPEN
RISQUE CHOC NE PAS ENLEVER
:
:
HDMI
