1. Introduction
1-7-6. Header file
Header files are ASCII-format text files containing information such as recording conditions.
In a header file, each recording-condition entry is written on 1 line, with parameters separated by a comma (,). An example of a header file is
shown as follows.
Example of header file
DATASET TEST0001
VERSION 1
SERIES CH1_WX7K_PAAMP,CH2_WX7K_PAAMP,CH3_WX7K_PAAMP,CH4_WX7K_PAAMP,CH5_WX7K_PAAMP,CH6_WX7K_PAAMP,CH7_WX7K_
PAAMP,CH8_WX7K_PAAMP
DATE 01-01-2013
TIME 12:00:00.00
RATE 192000
VERT_UNITS V,V,V,V,V,V,V,V
HORZ_UNITS Sec
COMMENT WX-7000
NUM_SERIES 8
STORAGE_MODE INTERLACED
FILE_TYPE INTEGER
SLOPE 8.000000e-005,8.000000e-005,8.000000e-005,8.000000e-005,8.000000e-005, 8.000000e-005,8.000000e-005,8.000000e-005
X_OFFSET -1.0
Y_OFFSET 0.000000e+000,0.000000e+000,0.000000e+000,0.000000e+000,0.000000e+000, 0.000000e+000,0.000000e+000,0.000000e+000
NUM_SAMPS 11904000
DATA
DEVICE WX-7000
CH1_1 WX7K_PAAMP,RANGE=2V,AC,4mA,FLAT,OFF,24V
CH2_2 WX7K_PAAMP,RANGE=2V,AC,4mA,FLAT,OFF,24V
CH3_3 WX7K_PAAMP,RANGE=2V,AC,4mA,FLAT,OFF,24V
CH4_4 WX7K_PAAMP,RANGE=2V,DC,OFF,FLAT,OFF
CH5_5 WX7K_PAAMP,RANGE=2V,DC,OFF,FLAT,OFF
CH6_6 WX7K_PAAMP,RANGE=2V,DC,OFF,FLAT,OFF
CH7_7 WX7K_PAAMP,RANGE=2V,DC,OFF,FLAT,OFF
CH8_8 WX7K_PAAMP,RANGE=2V,DC,OFF,FLAT,OFF
REC_MODE RDX
END_TIME 01-01-2013 12:01:00
START_TRIGGER COMMAND,PRE
STOP_CONDITION COMMAND,POST
START_PRE_COUNT 192000
STOP_POST_COUNT 192000
MARK 4032000,5952000,7872000
VOICE_MEMO 8BITS,327680
WX-7000_VERSION MAIN_FW:V1.00,MAIN_FPGA:V1.00,SUB_FW: :V1.00,LCD_FW:V1.00,AMP_DSP0:V 1.00,AMP_FPGA0:V 1.00
