1. Introduction
Explanations of header file
DATASET File name
VERSION 1 (This is a fixed value.)
SERIES Number of the channel used for recording. The channel name is after the underscore.
DATE Date when recording started (month-day-year)
TIME Time when recording started (hour: minute: second)
RATE Sampling frequency (Unit: Hz)
VERT_UNITS Physical/engineering units of each channel
HORZ_UNITS Time axis units (Sec: This is a fixed value)
COMMENT Comment entered using FILE and RECORDING FILE.
NUM_SERIES Number of recording channels
STORAGE_MODE Data order. Fixed as INTERLACED because this is the scan order.
FILE_TYPE In 16 bits A/D, INTEGER (1data,2-byte integers)
In 24 bits A/D, LONG (1data,4-byte integers)
SLOPE Coefficient used when converting data to physical/engineering units
X_OFFSET Location of the beginning data on the time axis. Usually is 0.
The setting value (number of seconds to three decimal places) is written in minus for the pre-trigger
time.
Even if you set the number of scans for Pre-trigger, this will be in seconds.
Y_OFFSET Offset used for converting data to physical/engineering units.
NUM_SAMPS Number of data items recorded per channel
DATA The data that follows this entry is specific to this unit, and it might differ from the formats of other
models.
DEVICE WX-7000
CH1_ The following information is written after the underscore: channel number, channel name, amplifier
setting(range, coupling, PA current, weighting, HPF, PA voltage)
REC_MODE Recording destination device (RDX, SD, PC)
END_TIME Recording end time
START_TRIGGER Recording start conditions: COMMAND: Interface command
LEVEL: Level trigger
DATE: When Repeat Count is 1 in the interval action
TIMER: When Repeat Count is 2 or more in the interval action
EXT: External Trigger
TIME_OUT: Time out
PRE: Added for a pre-trigger
STOP_CONDITION Recording stop conditions: COMMAND: Interface command
LEVEL: Level trigger
TIMER: Specified recording time
EXT: External trigger
MEDIA_FULL: The media is full.
POST: Added for a post-trigger
START_PRE_COUNT Number of scans recorded by a pre-trigger
STOP_POST_COUNT Number of scans recorded by a post-trigger
MARK Number of scans at the instant an event mark was attached.
VOICE_MEMO The number of bits per sample for voice-memo data. Data size (bytes)
WX-7000_VERSION Firmware and FPGA version of the WX-7000 main,
Firmware version of the WX-7000 sub, Firmware version of the LCD,
DSP and FPGA version of the WX-7000 amplifier
o In media recording, the WX-7000 attaches the following information after DEVICE when the data are automatically divided into segments of
maximum size(4GB).
DIVIDED n The n th file
o In synchronization recording, the WX-7000 attaches the following information after DEVICE.
SYNC MASTER In the case of a master unit in synchronization recording
(SYNC SLAVE) In the case of a slave unit in synchronization recording
