Technaxx TX-29 User Manual

31
Settings  Device manage:
Add
By checking the box in front of one or more devices from the device list
and then pressing Add the selected devices will be add to a Area.
Quick setup
All devices in the device list will be added
Add area
Add areas for organizing the cameras.
Add device
Add a device manually by filling in all needed information.
Modify device
Edit the device settings.
Clear devices
All devices are deleted from the area.
Flush
Refresh device list.
Assign IP
Edit IP address.
Settings  Device settings:
Device
information
By clicking on a device from the device list you get several
information’s about the device. Note: Information of the device is only
available from added devices. Click on the device from the list.
General setting
Set date format, HDD overwrite or dwell interval for full screen or
screen divided.
Network setting
Set DHCP on/ off, set the port, see P2P ID and set PPPoE on or off.
Encoding setting
Set main and sub stream settings like encode mode, encoding format,
quality, bit and frame rate.
Record settings
Set the record plan for every channel, select Timing, Motion or/and
Sensor (see chapter 5.3 record setup  record plan).
Screen settings
Set the channel name of the channel.
PTZ settings
Set different options for the PTZ.
Video detection
settings
Set the sensitivity, duration, alarm and buzzer for motion detect and
video loss (see chapter 5.3 channel setup  video detection).
Alarm settings
Set alarm, buzzer, work mode and alarm duration.
Channel mode
setting
Set the amount of analogue and digital channel the NVR should
support.
Settings  Local settings:
General settings
Set language, import or export setting information, automatically
synchronize time and connect devices on start up.
Record settings
Set the record plan for every channel, select Timing or/and motion (see
chapter 5.3 record setup  record plan).
Storage settings
Set the local disk letter, HDD overwrite and HDD reserved.

Technaxx TX-29 Specifications

General

LED type	IR
Rotating	-
Megapixel	1 MP
Sensor type	CMOS
Heat function	No
Camera included	Yes
Camera interface	Wi-Fi/RJ-45
Camera resolution	1280 x 720 pixels
Number of cameras	1
Fixed focal length	4 mm
Optical sensor size	1/4 \
Placement supported	Indoor
Camera shutter speed	1/25 - 1/25000 s
Minimum illumination	0.01 lx
Night vision distance	15 m
Connectivity technology	Wired & Wireless
Surveillance camera form factor	Bullet
International Protection (IP) code	IP66
Placement	Table, Wall
Display type	LCD
Display diagonal	10.1 \
HDD size	2.5 \
Video in	AV
HDD interface	Serial ATA
Channels quantity	- channels
Storage media type	HDD
USB 2.0 ports quantity	2
Maximum internal memory	4000 GB
Supported network protocols	UPnP, SMTP (SSL), PPPoE, DHCP, DDNS
Supported video modes	720p
Video compression formats	H.264
Ethernet interface type	Fast Ethernet
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Camera depth	150 mm
Camera width	97 mm
Camera height	87 mm
Camera weight	550 g
Display depth	250 mm
Display width	36 mm
Display height	166 mm
Display weight	1000 g
