2 Overview and Controls
This section provides information about front panel and rear panel. When you install this series
DVR for the first time, refer to this part first.
2.1 Front Panel
There is no button on the front panel of the Smart Box. There is no need to introduce the
front panel.
2.1.1 Midi Security Kit PRO FullHD1080P TX-51
The front panel is shown as below. See Figure 2-1.
Figure 2-1
Refer to the following sheet for front panel button information.
SN Name Function
1 HDD status indictor light The red light becomes on when HDD is abnormal.
2 Power indicator light
The red light becomes on when the power
connection is OK.
3
Network status indicator
light
The red light becomes on when the network
connection is abnormal.
