In Figure 4-15, input Scan value and then click to call a tour. Click again to stop
call.
Rotate
In Figure 4-15, click to enable the camera to rotate.
System supports preset, tour, pattern, scan, rotate, light and etc function.
Note:
 Preset, tour and pattern all need the value to be the control parameters. You can define it as
you require.
 You need to refer to your camera user’s manual for Aux definition. In some cases, it can be
used for special process.
Aux
Click
, system goes to the following interface. The options here are defined by the protocol.
The aux number is corresponding to the aux on-off button of the decoder. See Figure 4-21.
Figure4‐21
4.4.3 Color
Here you can set hue, brightness, contrast, saturation, gain, white level, color mode and etc.
See Figure 4-22.
Figure4‐22
