Technaxx TX-51 User Manual

35
Item Note
Position It is to adjust the image position on the screen.
Customized Click it to set customized color mode.
4.4.4 Search
Refer to chapter 4.8.1 for detailed information.
4.4.5 Manual Record
Refer to chapter 4.10.4.3.1 for detailed information.
4.5 Navigation Bar
You need to go to the Main menu->Setting->System->General to enable navigation bar
function; otherwise you can not see the following interface.
The navigation bar is shown as below. See Figure 4-23.
Figure 4-23
4.5.1 Main Menu
Click button to go to the main menu interface.
4.5.2 Output Screen
Select corresponding window-split mode and output channels.
4.5.3 Favorites
Click , system pops up the favorites schemes. Click one item, you can view saved favorite
channel split mode and channel number. See Figure 4-24.
Note, right now the favorite scheme name after the window split mode.

Figure 4-24
4.5.4 Tour
Click button to enable tour, the icon becomes , you can see the tour is in process.
4.5.5 PTZ
Click , system goes to the PTZ control interface. refer to chapter 4.4.2.
