Technaxx TX-51 User Manual

8
1.3 Specifications
1.3.1 Midi Security Kit PRO FullHD1080P TX-51
Parameters
System Main Processor Industrial embedded micro controller
OS Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P /720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Frame
Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type Video stream/composite stream
Dual-Stream Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate 64Kbps
Video Port Analog Video
Input
4-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output N/A
Matrix Output N/A
Audio Port Audio Input N/A
Audio Output N/A
