29
Figure4‐13
In the middle of the eight direction arrows, there is a 3D intelligent positioning key. See Figure
4-14. Make sure your protocol supports this function and you need to use mouse to control.
Click this key, system goes back to the single screen mode. Drag the mouse in the screen to
adjust section size. The dragged zone supports 4X to 16X speeds. It can realize PTZ
automatically. The smaller zone you dragged, the higher the speed.
Figure4‐14
Name Function
key
function Shortcut
key
Function
key
function Shortcut
key
Zoom
Near
Far
Focus
Near
│
Far ►│
Iris
close
Open
In Figure 4-13, click to open the menu, you can set preset, tour, pattern, scan and etc.
See Figure 4-15.
Figure4‐15
Refer to the following sheet for detailed information.
Note the above interface may vary due to different protocols. The button is grey and can not
be selected once the current function is null. Right click mouse or click the ESC button at the
front panel to go back to the Figure 4-13.
