12
1 Getting started
DMS3-CTC-25-420 v1.0. Copyright © 2017 Technicolor. All rights reserved.
This document contains Technicolor proprietary and confidential information. Passing on and copying of this document, use, extraction and
communication of its contents, is not permitted without written authorization from Technicolor.
Ethernet LED
TV LED
Voice LED
Colour State Description
Green Solid on At least one active network device is connected to the Ethernet switch.
Blinking At least one Network device is connected to the Ethernet switch and
sending/receiving data.
Off No active Ethernet devices connected to the Ethernet switch.
This Ethernet LED provides an overall status of the Ethernet connections. Additiobally, each Ethernet port has its
own LED to indicate link integrity (or activity). For more information, see “Ethernet switch” on page 6.
Colour State Description
Green Solid on Your digital TV service is up.
Blinking Your digital TV service is up and there is activity.
Off Your digital TV service is down or the digital TV service is not included in
your subscription .
Colour State Description
Green Solid on Your VoIP telephony service is up.
Blinking Your VoIP telephony service is up and there is activity.
Off Your VoIP telephony service is down or the VoIP telephony service is not
included in your subscription.
