Technics SL-1500C Operating Instructions

English
(18)
Playing records
Speed select buttons
Indicators
·
3 4
2
Centre spindle

1

2

2
Preparation

1 Put a record (not included) on the turntable.

2 Take off the stylus cover and release the arm clamp.
18
1


Removing the stylus cover
Hold the stylus cover from its front
and back, and while pushing the
latch on the rear part (

), slowly
tilt the stylus cover downward (

).


Attaching the stylus cover
Hold the stylus cover from its
front and back, align with the
front of the cartridge, and
slowly lift it (

) taking care not
to damage the stylus.
Cartridge
Stylus cover
①
③
②
1
Press [ ] to turn the unit on.
33-1/3 rpm is automatically selected and
the indicator [33] lights.
2
Press [START-STOP].
The turntable starts revolving.
Attention

Do not press [START-STOP] when the turntable is removed.
If you have accidentally pressed [START-STOP]
·The indicator of the speed select button ([33] or [45]) starts blinking.


If it is blinking, press [ ] to turn the unit off, fit the turntable and then press [ ] to turn
the unit on.

Turn the unit on or off with the volume on the connected device set to the minimum.
ピピ フブ
ヘベ
ヴヵモンヵ〔ヴヵヰヱ
ピピ
Indicator

Technics SL-1500C Specifications

General

Drive Method	Direct Drive
Wow and Flutter	0.025% WRMS
Platter	Aluminum Die-cast
Phono EQ	Built-in
Weight	9.9 kg
Motor	Brushless DC Motor
Effective Tonearm Length	230 mm
Overhang	15 mm
Phono Output	Yes
Line Output	Yes
Auto Lift	Yes
USB Output	No
Bluetooth	No
Power Supply	AC 110 - 240 V, 50/60 Hz
Turntable Speeds	33 1/3, 45, 78 rpm
Tonearm Type	Static Balance
Cartridge	Ortofon 2M Red
Dimensions	453 x 169 x 372 mm
Signal-to-Noise Ratio	78 dB
