Technidea ZIPLEVEL PRO-2000 User Manual

You’re about to enter an exciting new labor saving world of elevation mea-
surement and leveling. The ZIPLEVEL
®
PRO-2000 High Precision Altimeter
lets you focus on your work rather than the tedious task of measuring your
work. ZIPLEVEL
®
is the rst instrument of its kind to let you truly work alone,
set-up instantly and measure without line-of-sight, distance error, factory
calibration or math.
Unlike conventional builder’s and laser levels, ZIPLEVEL
®
displays verti-
cal measurements directly in large, easy to read digits. Select one of six
scales and cover up to 40’ (12m) vertically with 0.050” (1mm) precision over
a 200’ (60m) circle on a single set-up – equivalent to owning ve 40’ (12m)
rods and an imaginary 20’ (6m) tripod. The High Precision function provides
paper-thin precise vertical readings within 0.005” (0.1mm) over 4’ (1.2m). A
built-in Carry Function retains your original benchmark Zero over unlimited
ranges without the differential leveling tabulation, tedious calculations and
endless errors.
INTRODUCTIONZIPLEVEL SYSTEM CONCEPT
200’ (60m) CIRCLE
SINGLE SET-UP RANGES
+20’ (6m)
Unipod
Measurement
Module*
Cord
Base Unit
*Zero at any reference
within range
-20’ (6m)

Technidea ZIPLEVEL PRO-2000 Specifications

Ranges

set-up vertical range	40’ (12m)
set-up horizontal range	200’ (60m)
carry function range	No limit

Accuracy

reading repeatability	0.1” (2mm) or 0.01” (0.2mm) HP
leveling accuracy	0.1” (2mm) or 0.01” (0.2mm) HP
elevation accuracy	Greater of 0.1” (2mm)/0.01” (0.2mm) HP or 0.2% reading <10’ (3m) & 0.35% reading >10’

Capacity

record capacity	16, 384
record data capacity	137 readings
settings/data retention	Indefinitely, even without battery

Operating Environment

operating temperature range	-22°F to +158°F (-30C to +70C)
storage temperature range	-40°F to +158°F (-40C to +70C)
shock resistance	Measurement Module – 5’ (2m) drop on concrete

Battery

battery type	9V alkaline
battery life	60 hours active use
auto shut-off time	4 minutes inactive
