Technidea ZIPLEVEL PRO-2000 User Manual

Use any of ZIPLEVEL’s 16 powerful built-in functions to master tough ele-
vation measuring and leveling tasks from estimating, planning, excavation,
construction and landscaping to fabrication, checking and analysis. Attach
the optional PC Serial Link to ZIPLEVEL’s built-in Serial Port and make
ZIPLEVEL
®
a powerful data gathering instrument capable of downloading
stored measurements to a Personal Computer for analysis and tabulation or
plots of proles, sections and topographical maps.
Carefully review this User Guide and with a little practice you’ll soon cut
time, cost and frustration from your work.
INTRODUCTION
ZIPLEVEL
®
Basics .............................. 1-6
Quick Start ....................................... 7
On/Off, Hold & Zero........................... 9
Scale & Resolution ............................ 11
Calibration ........................................ 13
Record ............................................. 15
Mark ................................................ 17
Temperature & High Precision ............ 19
Carry ................................................ 21
Record Data ..................................... 23
Inspect/Dump & Initialize ................... 25
Elevation .......................................... 27
Monitor ............................................. 29
Display Alarm Indicators .................... 30
Use Tips ........................................... 31
How to Measure Accurately ................ 32
ZIPLEVEL
®
Care ................................. 34
Troubleshooting ................................ 36
Maintenance/Product Assistance ........ 37
ZIPLEVEL
®
Specifications ................... 38
LABELED
FUNCTIONS
HIDDEN
FUNCTIONS
TABLE OF CONTENTS

Technidea ZIPLEVEL PRO-2000 Specifications

Ranges

set-up vertical range	40’ (12m)
set-up horizontal range	200’ (60m)
carry function range	No limit

Accuracy

reading repeatability	0.1” (2mm) or 0.01” (0.2mm) HP
leveling accuracy	0.1” (2mm) or 0.01” (0.2mm) HP
elevation accuracy	Greater of 0.1” (2mm)/0.01” (0.2mm) HP or 0.2% reading <10’ (3m) & 0.35% reading >10’

Capacity

record capacity	16, 384
record data capacity	137 readings
settings/data retention	Indefinitely, even without battery

Operating Environment

operating temperature range	-22°F to +158°F (-30C to +70C)
storage temperature range	-40°F to +158°F (-40C to +70C)
shock resistance	Measurement Module – 5’ (2m) drop on concrete

Battery

battery type	9V alkaline
battery life	60 hours active use
auto shut-off time	4 minutes inactive
