Installation / Operation Manual
The probe is constructed of two concentric tubes. Wetted and internal surfaces are
coated with a fused epoxy powder. The inner tube is insulated from the outer tube by
PTFE (polytetrafluoroethylene) spacers and is electrically connected to a terminal within
the sensor housing. The internal element spacers can be fitted with trimmer rods should
it be necessary to adjust the base capacitance.
Nominal
Pipe Size
Catalog Model
Number
Stock
Number
2"
3"
4"
6"
CX-645-200-BGP
CX-645-300-BGP
CX-645-400-BGP
CX-645-600-BGP
81001190
81001195
81001200
81001205
2"
3"
4"
6"
CX-645-200-BFP
CX-645-300-BFP
CX-645-400-BFP
CX-645-600-BFP
81001191
81001196
81001201
81001206
2"
3"
4"
6"
CX-645-230-BGP
CX-645-330-BGP
CX-645-430-BGP
CX-645-630-BGP
81001192
81001197
81001202
81001207
2"
3"
4"
6"
CX-645-260-BGP
CX-645-360-BGP
CX-645-460-BGP
CX-645-660-BGP
81001193
81001198
81001203
81001208
Note: Field Conversion kit to modify Model CX-201 Probes to CX-645 configuration
available. Stock No. 49020402
Pipe Sizes Available
Pipe Size Dim. "A"
2" 17"
3", 4", 6", 8" 32"
