TechniSat TechniStar S2 Quick Start Manual

7.4.2 Using the numeric pad keys
> Use the numeric keypad keys to enter the number of the channel you want.
For example:
1 for channel 1
1, then 4 for channel 14
2, then 3, then 4 for channel 234
1, then 5, then 6 then 7 for channel 1567
When entering channel numbers with several digits, you have approx. three seconds after
pressing a key to complete the entry.
If you wish to enter a number consisting of only one, two or three digits, you can speed up
the entry procedure by keeping the key depressed a little longer on the last digit.
7.4.3 Using the Navigator (channel list)
> Press the OK button.
The channel list navigator is now displayed. In TV mode only TV channels are shown,
and in radio mode only radio channels are shown.
The channel currently selected is highlighted.
> You can view additional data about the current programme by pressing the INFO
button.
7.4.3.1 Selecting a channel
> You can now use the arrow keys to highlight the channel you want.
Using the up/down arrow keys move the cursor to a line and use the right/left
arrow keys to move up or down a page.
> Press the OK button to select the highlighted channel.
7.4.3.2 Selecting a list
To make it easier for you to find channels, your device provides various channel lists. You
can select your Favourites lists, or display channels in a Full list sorted alphabetically,
or by provider, or by genre.
> Press the OK button.
The active channel list is now displayed.
> You can now use the Option button to open a window containing the channel list
types (TV list, Astra list, TV provider lists, TV genre lists and TV full
list).
22

TechniSat TechniStar S2 Specifications

General

Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
PC in (D-Sub)	No
USB ports quantity	3
S-Video inputs quantity	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	MP2, MP3
Image formats supported	JPG
Video formats supported	TS, VOB
Ethernet LAN	Yes
Product color	Black
Audio decoders	Dolby Digital Plus
Input frequency range	950 - 2150 MHz
Video compression formats	MPEG2
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Package weight	1600 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	37 mm
Weight	600 g
