TechniSat TechniStar S2 Quick Start Manual

2.5 Important information on data security
Before handing your receiver over to your supplier for maintenance purposes, we
recommend that you remove all storage media or data carriers.
Restoring data is not part of maintenance or repair work. TechniSat accepts no responsibility
for the loss of, or damage to, data during repair work.
3 Remote control
3.1 Changing the battery
> Open the cover on the battery compartment at the rear of the remote control by
pushing it in the direction of the arrow and then lifting it off.
> Insert the supplied batteries, ensuring that the poles are the right way around (indicator
visible in battery compartment).
> Close the battery compartment again.
3.2 Remote control code
By switching over the remote control option it is possible to use this remote control to
operate a TechniSat television and two TechniSat receivers using the same coding.
> To switch over the remote control option, press the button you want (SAT1, SAT2 or
TV) and OK at the same time.
7

TechniSat TechniStar S2 Specifications

General

Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
PC in (D-Sub)	No
USB ports quantity	3
S-Video inputs quantity	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	MP2, MP3
Image formats supported	JPG
Video formats supported	TS, VOB
Ethernet LAN	Yes
Product color	Black
Audio decoders	Dolby Digital Plus
Input frequency range	950 - 2150 MHz
Video compression formats	MPEG2
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Package weight	1600 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	37 mm
Weight	600 g
