8 Operating the DVR
Your receiver has a DVR function (DVR = Digital Video Recorder) and a slot for USB
devices. You can use this as a recording medium.
A USB device must be inserted as a recording medium in order to record.
The recording capacity thus depends on the size of the recording medium and the volume of
data in the programme.
When recording, the teletext data and subtitles (where broadcast) are also recorded as well
as the actual audio and video data.
8.1 Organising recording media
To be able to make recordings on one of the media mentioned above, this must be
formatted for either FAT32 or the TechniSat file system.
> First press the Menu button to access the Main menu.
> Use the up/down arrow keys to highlight the Recording Media Organiser
option and press OK.
The Recording media organiser menu is displayed and the Automatic option
is highlighted.
> Now press the OK button to open a window with the inserted media.
> Use the up/down arrow keys to select the medium that needs to be formatted and
press the OK button.
34

TechniSat TechniStar S2 Specifications

General

Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
PC in (D-Sub)	No
USB ports quantity	3
S-Video inputs quantity	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	MP2, MP3
Image formats supported	JPG
Video formats supported	TS, VOB
Ethernet LAN	Yes
Product color	Black
Audio decoders	Dolby Digital Plus
Input frequency range	950 - 2150 MHz
Video compression formats	MPEG2
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Package weight	1600 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	37 mm
Weight	600 g
