TechniSat TechniStar S2 Quick Start Manual

3
* This function is only
available where the
corresponding data
is broadcast by the
channel on the selected
programme slot.
On/Standby
Sound on/off
Numeric keys
Recording
Left arrow key
Up arrow key
Down arrow key
SFI (EPG)
Channel +
Channel -
Teletext On/Off*
Right arrow key
Volume -
Volume +
Info
Language selection*
TV/Radio mode
Back
PIP (picture in picture)
Freeze frame
jog shuttle on/off
Sleep timer
Menu on/off
0/AV
Option*
in TV mode:
Select sound track/
subtitles, special functions
in Radio mode: Select
stations by switching sound
sub-carriers
Channel list On/Off
OK
Blue Fast forward,
Zoom/format
Yellow Pause,
playback
Red Rewind
Green Stop,
DVR Navigator
Remote control option:
by switching on the remote control option, two receivers and one TechniSat TV with the same coding can be
operated using this remote control.
> To switch over the remote control option, press the button you want (SAT1, SAT2 or TV) and OK
at the same time.
Note:
to use this receiver, the remote control option selected here for the remote control and the remote control
code must match.
Multi-function keys

TechniSat TechniStar S2 Specifications

General

Audio output channels	- channels
Power output per channel (20-20KHz@8 Ohm)	- W
PC in (D-Sub)	No
USB ports quantity	3
S-Video inputs quantity	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	MP2, MP3
Image formats supported	JPG
Video formats supported	TS, VOB
Ethernet LAN	Yes
Product color	Black
Audio decoders	Dolby Digital Plus
Input frequency range	950 - 2150 MHz
Video compression formats	MPEG2
Apple docking compatibility	Not supported
On Screen Display (OSD) languages	DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Package weight	1600 g

Weight and Dimensions

Depth	135 mm
Width	280 mm
Height	37 mm
Weight	600 g
